Ceramic cutting insert is widely used for machining steel parts (mainly steel, such as high manganese steel, hardened steel etc); mainly used in roughing, semi finishing and finishing.

New developed grade of RCGX ceramic insert shows excellent wear resistance, heat resistance, high toughness and good resistance to plastic deformation because of the additional metal elements.

Compared with conventional ceramic materials, the composite tool material has higher strength and fracture toughness, so the indexable turning insert processing range has been extended from finishing and semi finishing to rough machining.

The grade has higher temperature resistance than conventional CBN. It is suitable for turning application for cast iron, hardened steel, at high speed hard turning

All hard turning CNC insert are available in our product range.

Order No.	Dimension(mm)				Grades
ISO	L	Φi.c	s	r	BCE	CE	2CE
RCGX060600		6.35	6.35		□	□	□	□
RCGX090700		9.53	7.94		□	□	□	□
RCGX120700		12.70	7.94		□	□	□	□
RCGX150900		15.88	9.53		□	□	□	□
RCGX160900		16.00	9.53		□	□	□	□
RCGX191000		19.05	10.00		□	□	□	□

Order No.	Dimension(mm)				Grades
ISO	L	Φi.c	s	r	BCE	CE	2CE
RCGV060600		6.35	6.20		□	□	□	□
RCGV090700		9.525	7.70		□	□	□	□
RCGV120700		12.70	7.70		□	□	□	□
RCGV151000		15.88	9.77		□	□	□	□
RCGV191000		19.05	9.77		□	□	□	□
RCGV251200		25.40	11.58		□	□	□	□

Order No.	Dimension(mm)				Grades
ISO	L	Φi.c	s	r	BCE	CE	2CE
RPGV060600		6.35	6.35		□	□	□	□
RPGV090700		9.525	7.94		□	□	□	□
RPGV120700		12.70	7.94		□	□	□	□
RPGV151000		15.88	9.53		□	□	□	□
RPGV191000		19.05	10.00		□	□	□	□
RPGV251200		25.40	11.58		□	□	□	□
